Autel IM608 PRO2 Program 2014 Toyota RAV4 All Keys Lost

Now I'm working on a 2014 Toyota RAV4 with all keys lost. Next, I'm gonna use the Autel MaxiIM IM608 PRO II to program a new blade key for this car.

IMMO >> Auto VIN >> Toyota >> OK >> OK >> Control unit >> Immobilizer(H 8A/8E) >> Immobilizer reset(all keys lost)
This function is only supported for the Middle East and the USA now.

Ensure that the door remains open during the learning process.
Enter the number of keys to be registered: 1
Turn the ignition off.
Turn the ignition on.
Turn the ignition off and remove the key.
Turn the ignition on.
Turn the ignition off and remove the key.

Follow the following steps to learn 1 master key within 120s:
1)Insert the master key, turn the ignition on, and wait for 5s. Then quickly turn the ignition on and back off 5 times until the SECURITY lamp goes out, which indicates that learning is completed.

Test the new key, it can start the engine normally.
Done.

This is using Autel IM608 Pro2 to program the 2014 Toyota RAV4 with all keys lost successfully.

www.obd2shop.co.uk

Oznake: autel im608 ii

15.05.2024. u 05:35 • 0 Komentara • Print • # • ^

četvrtak, 31.08.2023.

How to use Autel MaxiIM IM608 II to add a key for 2011 VW GTI

This post will guide you on how to use the Autel MaxiIM IM608 PRO 2 key programmer to add a new key for the 2011 Volkswagen GTI.

The tools we need:

Autel IM608 Pro 2
Autel X400 PRO
A Volkswagen GTI working key
A new blank key

First, take the original key set it into the ignition, and turn the ignition on.

Then select IMMO on the IM608 Pro 2 tablet.

Select "Volkswagen" >> "Smart selection", confirm the vehicle information, and click "Yes" to continue.

After coming to the following interface, select "Add Key", then click "Yes" to continue.

Next are the three operations of "Add key".

1. Read IMMO data
2. Make dealer key
Do you want to generate a dealer key? Click "Yes".
Then place a blank key into the key slot of the programmer and press OK.
The dealer key was generated successfully.

3. Add keys to the vehicle
Place the dealer key into the key slot of the programmer
Entering programming mode. It may take a long time...
Key added successfully.

Then go back to the "Function selection" interface and select "Add remote control".

Press the unlock button on the door, then choose "OK" to continue.

Press any button of the key within 10s.
Remote control adding succeeded.

Let's test everything out, turn the ignition off, pull out the original key, and then insert the new key.
The car starts and runs with the new key!

Tech support: www.obd2shop.co.uk

Oznake: autel im608 ii

31.08.2023. u 11:49 • 0 Komentara • Print • # • ^

ponedjeljak, 06.02.2023.

Autel IM608 II vs. Xhorse Key Tool Plus vs. Launch X431 IMMO Pad

As the hot sales in the key programming market, what's different between Autel MaxiIM IM608 II, Xhorse VVDI Key Tool Plus Pad & Launch X431 IMMO Pad? Which tool is better? Reading the comparison table may help you make it clear.

Key Programmer: Autel vs. Xhorse vs. Launch

Conclusion

In terms of price, Autel IM608 Pro2 is the most expensive, Xhorse Key Tool Plus is the cheapest, and X431 IMMO Pad is between them.
In the IMMO function aspect, IM608 Pro2 covers a wider range of models and takes the lead in FCA, Ford, GM, Honda, Hyundai, Kia, and Nissan. Key Tool Plus do better in Mercedes, BMW, VAG, and Toyota. X431 IMMO Pad has an advantage in reading/ writing/ cloning Mercedes, BMW, VAG ECM, and TCM. Besides, both IM608 Pro2 & Key Tool Plus support generating universal keys directly.
As for diagnostic functions, IM608 Pro2 is specialized in coding, guiding, and BMW, Mercedes immo programming. X431 IMMO Pad is comprehensive in read/clear codes and coding. Key Tool Plus does not support it.
In the hardware configuration, IM608 Pro2 is the latest while the all-in-one Key Tool Plus is more portable.
As regards the extended features, X431 IMMO Pad supports more, IM608 Pro2 supports less while Key Tool Plus does not support it.

On the whole, whatever brand has its advantages and disadvantages in different models. All 3 key programmers also have functions that they are better at. Customers can pick one based on budget and car models or features they frequently use.

www.obd2shop.co.uk

Oznake: autel im608 ii

06.02.2023. u 10:38 • 0 Komentara • Print • # • ^
